AURATON 2020 - Connection diagrams; Diagram of direct AURATON 2020 RX Plus connection to a heating device

1. AURATON 2020 RX Plus (receiver).
2. AURATON 2020 TX Plus located in any room.
Note: In case of most of the heating device the short-circuit connector of the connection cube should be removed
and replaced with the receiver wires.
In case of any doubts please contact the dealer or manufacturer.
1
2
18.5 Diagram of direct AURATON 2020 RX Plus
connection to a heating device
NO
COM
NC
AUTO
MAN
TH
PROG
:
0
C
a heating
device
for example
a gas furnace
57
EN
AURATON 2020 TX RX Plus - Connection diagrams
