Autel MaxiBas BT508 - Technical Specifications

6
Internal Battery Pack
The BT508 is powered via its internal rechargeable battery.
AC/DC Power Supply — Using Power Adapter
The tester can be powered from an electrical outlet using the AC/DC power
supply. The AC/DC power supply also charges the internal battery pack.
2.1.3 Technical Specifications
Item
Description
Connectivity
 USB 2.0, Type C
 Bluetooth 4.2
Input Voltage
5 V DC
Working Current
< 150 mA at 12 V DC
CCA Range
100 to 2000 A
Voltage Range
6 to 36 V
Working Temperature
-10 ° C to 50 ° C (14° F to 122° F)
Storage Temperature
-20 ° C to 60 ° C (-4° F to 140° F)
Dimension (L x W x H)
107 mm (4.21’’) x 75 mm (2.95”) x 26 mm (1.02”)
(clamp cable not included)
Weight
320 g (0.7 lb.)
