Autel MaxiSys Mini - Technical Specifications

General Introduction MaxiSys Display Tablet
6
2.1.3 Technical Specifications
Item
Description
Operating System
Android
TM
4.0, Ice Cream Sandwich
Processor
Samsung Exynos Quad-Core Processor 1.4GHz
Memory
2GB RAM & 32GB On-board Memory
Display
8.0 inch LED capacitive touch screen with
1024x768P resolution
Connectivity
 Wi-Fi (802.11 a/b/g/n)
 USB: 2.0
 Bluetooth v.2.1 + EDR
Camera (rear)
Rear-facing, 5.0 Megapixel, AF with Flashlight
Sensors
Gravity Accelerometer, Ambient Light Sensor
(ALS)
Audio Input/Output
 Microphone
 Dual Speakers
 4-Band 3.5 mm stereo/standard headset jack
Power and Battery
 5000 mAh 3.7 V lithium-polymer battery
 Charging via 12 V AC/DC power supply
Input Voltage
12 V (9-24 V)
Power Consumption
3.9 W
Operating
Temperature
-10 to 55°C (14 to 131°F)
Storage Temperature
-20 to 70°C (-4 to 158°F)
Housing
Strong plastic housing with protective rubber boot
Dimensions (W x H x D)
221 mm (8.7”) x 160 mm (6.3”) x 20 mm (0.78”)
Weight
NW: 0.67 kg (1.48 lb), GW: 8.534 kg (18.81 lb)
Protocols
ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L lins,
Flashing Code, SAE-J1850 VPW, SAE-J1850
PWM, CAN ISO 11898, Highspeed, Middlespeed,
Lowspeed and Singlewire CAN, GM UART, UART
Echo Byte Protocol, Honda Diag-H Protocol, TP
2.0, TP 1.6, SAE J1939, SAE J1708,
Fault-Tolerant CAN
