Data Manager Operations Operations
55
Figure 5-2 Sample Image Database Screen
1. Toolbar Buttons – used to edit, print and delete the image files. See
Table 5-1 Toolbar Buttons in JPG Database on page 55 for detailed
information.
2. Main Section – displays the stored images.
Table 5-1 Toolbar Buttons in JPG Database
Name
Button
Description
Back
Returns to the previous screen.
Enter Edit
Touching this button shows the editing toolbar
to print, delete or view image information.
Cancel
Touching this button close the editing toolbar
or cancels file search.
Search
Quickly locates the image file by entering the
vehicle name, test path, file name or file info.
Info
Touching this button opens a window
displaying the detail information of the image.
Print
Touching this button prints the selected image.
Delete
Touching this button deletes the selected
image.
