Calidus
SYSTEM DESCRIPTION
AutoGyro_POH_Calidus Revision 4.0 – Issue Date 17.JAN.2019 7-13
The aft stick is held by means of 2 bolts, self-locking nuts and a pair of distance washers
within a bracket and should be removed unless the seat is occupied by a qualified flight
instructor.
View of the two rear stick attachment bolts. After re fitting ensure that electrical cable does
not foul on the edge of the stick aperture on extremes of control stick movement.
CAUTION
When the front seat back is adjusted rearwards it is possible for the rear stick
grip to contact the back of the front seat, restricting the forward pitch
movement of the rear stick. In some markets removable stops are fitted to the
front seat adjustment straps to limit travel and prevent this issue.
Where the rear stick is fitted, always ensure that the front seat back is adjusted
so that there is no pitch forward restriction - before starting the engine!
