11. Revolving light The relay chosen with this function activates the revolving light on the opening or
the closing command.
The revolving light consequently operates:
-
before opening if the time-out before opening (parameter 7) is activated.
- during a barrier movement.
- before closing if the time-out after passage (parameter 3) is activated.
12. FCO copies the status of the input FCO (opening limit switch)
13. FCF copies the status of the input FCF (closing limit switch)
14. FCM copies the status of the input FCM (crank safety switch).
15. HS The relay chosen for this function is always activated. It goes back to rest position
in case of power failure or out of order status.
16. Arm swing-off The chosen relay is activated on detection of the lack of the arm.
Passage 1:
17. direction 1 300ms pulse when there is a detection for the passage 1-direction 1
18. direction 2 300ms pulse when there is a detection for the passage 1-direction 2
Passage 2
19. direction 1 300ms pulse when there is a detection for the passage 2-direction 1
20. direction 2 300ms pulse when there is a detection for the passage 2-direction 2
Note: The passage direction detected by the two sensors selected in the parameter14 or 15 is
defined from the smallest to the largest.
For example: From sensor 1 to sensor 2 = Direction 1, from sensor 2 to sensor 1 = Direction 2,
from sensor 1 to sensor 4 = Direction 1, from sensor 3 to sensor 1 = Direction 2.
IMPORTANT: Always ensure the continuity of the signal between the 2 sensors.
2.4.3.
Programming procedure
1. Note the setting of SW4 for operation mode (see chapter 2.3).
2. Set DIP 1 to 8 of the SW4 (1:15) to OFF.
3. Start programming by placing DIP 8 to ON.
4. The red LED LD2 (1:17) flashes slowly.
5. With DIP 1 to 7 in binary mode (see table below), set the number of the parameter to be
programmed (column 1 of the parameters chart, chapter 2.4.1)
6. Press PGM, SW5 (1:16) -the push button to enter the parameters.
7. The red LED LD2 (1:17) flashes quickly.
8. Set the value (in binary mode) or the choice with the DIP-switches.
9. Press PGM again (1:16).
10. The red LED LD2 (1:17) again flashes slowly, waiting for the introduction of a new parameter
number to be programmed.
11. To introduce a new parameter, return to step 5.
12. Return DIP 1-7 to OFF after introduction of all the parameters.
13. To exit the programming mode, set DIP 8 to OFF.
14. The logic board returns to operation mode.
15. Set the operation mode parameters noted on point 1.
