Automatic Systems Logic D1 v06-02-en0802.doc ERB-PM Technical manual
26/31
X3 (8:2): The Outputs
Terminal 61 is a 24V DC output from the board AS1200 and is limited to 150mA.
Terminal Use
61 24V 150mA max.
62 Ground
63 Boom lighting
64 Ground
65 Electromagnet of the electromagnetic tip support or
Solenoid of the electromechanical tip support
66 Relay 1 NO
67 Relay 1 Common
68 Relay 2 NO
69 Relay 2 Common
3.4.2.
The switch SW3
DIP N° Function OFF ON
1 Selection between 1 or 2 traffic lights 1 traffic light 2 traffic lights
2 Traffic light operation direction (if only one) Entry (OVB) Exit (DPO)
3 Green authorisation light (if only one) Continuous Blinking
4 Red light changeover After loop On loop
5 Electromagnetic tip support into service Disable Enable
6 Electromechanical tip support in operation Disable Enable
7 Boom lighting Blinking Continuous
8 Detection of the presence of the boom Disable Enable
3.4.3.
Lighting
When lit green, the LED’s have the following functions:
LD1 Entry command OVB in direction A
LD2 Entry command OVB in direction B
LD3 Presence of the boom in the electromechanical tip support
LD4 Activation of the bolt of the electromechanical tip support
LD5 Indication of boom lighting
LD6 Control of electromagnetic tip support
LD7 REL1 engaged
LD8 REL2 engaged
