Automatic Systems D1 User Manual

 Automatic Systems Logic D1 v06-02-en0802.doc ERB-PM Technical manual
31/31
7.
The AS1033 CONSOLE (<under development>)
Console to control, to visualise and to program the AS1200 board.
8.
The Board AS1210 (<option>)
13:1
Fig. 13
For specific applications, the board AS1210 is made to control the serial link RS232 (connector X2 (13:1)).
It is plugged into the connector X6 (1:6) of the AS1200 board and makes a PC connection possible.
