Automatic Systems D1 User Manual

 Automatic Systems Logic D1 v06-02-en0802.doc ERB-PM Technical manual
17/31
TABLE of various addresses:
Sensor
Position at the
connection
terminals on the
AS1200
Connector for
the sensor
board on the
AS1200
I²C Address Function
1
X7↑ 21 - 22
X3 LOW DP1
2
X7↑ 19 - 20
X3 LOW DP2
3
X7↑ 21 - 22
X3 HIGH DP3
4
X7↑ 19 - 20
X3 HIGH DP4
1
X7↑ 43 - 44
X4 LOW DP1
2
X7↑ 41 - 42
X4 LOW DP2
3
X7↑ 43 - 44
X4 HIGH DP3
4
X7↑ 41 - 42
X4 HIGH DP4
2.5.5.2. Sensor Functions
Many different types of functions give a choice for each sensor. These functions act differently on the
operation of the obstacle.
- 4 main functions for the sensors: DPI, DPO, DPFS, DPS.
1.
DPI Direct information (I) through the relay contacts; no influence to the movement.
2.
DPO Opens (O) the obstacle on reception of a presence detection from the sensor.
3.
DPFS Closing (F): Automatically at the end of the detection and.
Stop (S): stops the closing of the obstacle in case of the return of a detection.
Two actions may be added following the DPFS, (after S, safety stop):
a)
SF maintains the safety Stop (S) of the obstacle and
at the end of the detection, starts its closing (F).
b)
OF commands the opening (O) of the obstacle and
at the end of the detection, starts its closing (F).
4.
DPS Stop (S): stops the closing movement in case of detection.
Two actions may be added following the DPS, (after S, safety stop):
a)
S maintains the safety Stop (S) and waits for the following command.
b)
O starts the opening (O) and waits for the following command.
