3. Specifications
Technical Specifications
Power supply 230V - 240Va.c. 50Hz
Maximum door opening:
Width:
Height:
Weight:
5500mm (16.5 m
2
)
3000mm
100kg
Minimum sideroom 40mm
Lift force 500N (50kg)
Nominal force 150N (15kg)
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity GDO-6v3: 14 X 4 button Transmitter Codes
GDO-6v4: 64 x 4 button Transmitter Codes
Transmitter frequency TrioCode
TM
128 Technology
Coding type Mulit-frequency Code Hopping
Number of code combinations Over 100 billion random codes
Code generation Non-linear encryption algorithm
Transmitter battery CR2032 (3 Volts)
Courtesy light LED (Light Emitting Diodes)
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind
puts extra pressure on the door and tracks which may in turn intermittently trigger the safety obstruction
detection system.
