GDO-8v1 EasyRoller® II Owner Installation Instructions
Spare parts list
Item No Description Order code
1 Drive chassis sub-assy 01775
2 Internal gear axle 03015
3 Hex serration head screw M6x20 10171
4 Internal gear 16020
5 Clamp washer 11180
6 Retaining ring STW 45 10650
7 Mounting bracket VR1 02504
8 Clutch geared motor assy 12-01 WS 00374
9 Transformer TDB-72-01 Kit (72VA) 02035
10 Ratchet timing assy 01733
11 Power Cord A.S. 1.5m 2P 1R 05664
12 Felt 21 x 29 05609
13 Terminal block 500/02DS 2 POS 05421
14 Cap polyfi lm 0.1UF K X2 275 VAC 07575
15 Hex serration head screw M8x16 10122
16 Taptite screw ‘P’ M4x10 10570
17 Pan head screw w/washer M4x8 10320
18 Taptite screw ‘P’ black znc M3x14 10552
19 Internal tooth lo
ck washer I.D 3
11150
20 Cable tie 4” GT-100M 14160
21 String handle assy 01762
22 Control board CB-17 01010
23A Chassis enclosure assy 02851
23B Chassis enclosure LK AY (with lock) 02853
24 Control cover assy 03212
25 Industrial saddle 03175
26 U bolt M8 10141
27 Hex serration fl ange nut M8 (black) 10148
28 Flat washer 8.4
x18x1.6
11021
29 Securacode PTX-
4 & wallswitch pack
01220
30 Transmitter grey butt
ons PTX-4
01210
31 Transmitter red buttons PTX-4 01211
32 PTX holder 05196
33 Alkaline battery A23 1
2V
13030
34 Plastic wall plug pack 01479
35 Cover with D/S
tape
71040
36 Weight bar 71190
37 Weight bar accessory 01782
38 Security pack 01466
When ordering spare parts please quote the
order code number to your installer/distributor
