GDO-12 HIRO Installation Manual
5
2. Specifications
Technical Specifications GDO-12V1
Rated voltage range 230V - 240V a.c
Rated frequency 50Hz / 60Hz
Rated power input 150W
Rated operating time: 6 min
Rated operating temperature -10
o
C to +55
o
C
Rated load 500N
Maximum turns of door drum:
Max door weight:
Maximum door area (wind-lock):
Maximum door area:
Door must be well balanced and able to be operated by hand,
as per warranty conditions and standard AS/NZS 4505:2012
6 turns of the drum wheel
270kg *
22m2 **
28m
2
Minimum sideroom 35mm
IP rating IP20
Receiver type Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Receiver code storage capacity 64 x 4-button Transmitters
Number of code combinations Over 100 billion random codes
Transmitter battery CR2032 (3 Volts)
Courtesy light LED (Light Emitting Diodes)
*: Gross door weight, incl. all fittings
**: Windy conditions can activate the obstruction feature of the opener.
