Automatic Technology Hiro GDO-12V1 - Default Chapter; Table of Contents

Installation Instructions GDO-12V1 Hiro
™
3
1. Safety Information 4
2. Specifications 5
3. Set Up Requirements 6
4. Pre-Installation Requirements 7
4.1 Door Operation 7
4.2 Unsuitable Door Types 7
4.3 Position 7
4.4 Power Supply 7
4.5 Sideroom 7
4.6 Forks 7
5. Opener Safety & Security 8
5.1 The Door CAN NOT be used by the opener when: 8
5.2 The Door CAN be used when: 8
5.3 To Disengage the Opener: 8
5.4 To Re-Engage the Opener: 8
6. Installation Instructions 8
6.1 Door Preparation 9
6.1.1 Preparation 9
6.1.2 Pinning the Door to the drum: 9
6.2 Propping the Door 10
6.3 Fitting the Opener 10
6.4 Setting Limits 11
6.4.1 Setting Travel Limits 11
6.4.2 Set the Limit Positions 11
6.4.3 Resetting the Door Limit Positions 11
6.4.4 Setting Partial Open Position 11
6.4.5 Checking Partial Open Position 11
6.5 Safety Obstruction Force Test 12
6.5.1 Testing Close Cycle 12
6.5.1 Testing Open Cycle 12
6.6 Coding Transmitter 13
6.6.1 Transmitter Button to Operate Door 13
6.6.2 Erasing Programmed Codes 13
6.6.3 Selecting The Function To Be Coded 13
6.6.4 Activate Remote Code Set Mode 13
7. Operation Instructions 14
7.1 How to Use Your Opener 15
7.1.1 To Operate the opener: 15
7.1.2 Replacing the Battery: 3V Lithium Battery CR2032. 15
7.1.3 Battery Disposal 15
7.2 User Operating Controls 16
7.3 Door Status Indicators 16
8. Maintenance 17
9. Troubleshooting Guide 18
10. Appendix 19
A - Adjustment Mode Parameters 19
B - Motor Speed 19
C - LED Status 20
D - Setting Limits via Transmitter 21
E - Additional Transmitter Functions 22
11. Warranty and Exclusion of Liability 23
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or
otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener. Automatic
Technology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any
person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener in accordance with these
installation instructions.
High Roll Up Garage Door Opener
GDO-12
HiR
