GDO-12V1 Hiro
™
Installation Instructions
3. Set Up Requirements
Fig 3.1
3.1 Kit Contents
ITEM DESCRIPTION QTY
1 GDO-12 POWER DRIVE UNIT 1
2 INTERNAL GEAR ADAPTER (FORKS) 3
3 HEX SERRATION HEAD SCREW M6 X 20 6
4 4 BUTTON TRANSMITTERS 2
5 4 BUTTON WALL TRANSMITTER 1
6 LOCKING BAR COVERS 2
GUIDE PACK VR12
7 SCREW-EYE 2
8 PLASTIC WALL PLUG 6.9 X 25 (1”) 2
1
2
3
4
5
6
7
8
