Owner Installation Instructions NeoSlider
TM
- Sliding Gate Opener NES-24V3 5
Console Exit button
Console Down/Close button
Console SET button
Antenna connector
Console display
PG3 programmer / network connector
Motor connector
24VAC input connector
10 AMP slow blow fuse
Standby battery charger/solar
connector
3. Set Up Requirements
Fig 3.1
3.1 Kit Contents
3.2 Choosing your Set up
The NeoSlider™ can be set up in various ways and therefore may
require additional items. Common Set ups are as follows;
ITEM DESCRIPTION QTY ORDER
CODE
1 DRIVE UNIT NES-24V3 1 60188
2 TRIO-CODE 4B PTX-5V2 TRANSMITTER 2 61160
3 ACCESSORY ACTUATOR PACK 2 61463
1
2
3
Set Up Items Required
Automated Set Up Drive Unit and transmitter
Automated Set Up
with Safety Beams
Drive Unit, transmitter and safety beams
(optional)
CAUTION: Cables which have a green/yellow coloured
insulation are for earthing purposes only.
Never use these cables for any other purpose.
IMPORTANT WARNING!
A qualified electrician must
perform the installation where
240V AC power is used.
To Next Page
