GDO-7V1 SecuraLift® Owner Installation Instructions
Determine the door type
Determine which type of garage door you have as
illustrated below. (Fig. 3 -5). �
• For a sectional (panel) door on tracks (Fig. 3) proceed
with the installation from Step 5. �
• For a one piece door on tracks (Fig. 4) proceed with
the installation from Step 5. � For a one piece door
without tracks (on springs) (Fig. 5) proceed with the
installation from Step 9.
- 9 -
©Copyright 2006 Automatic Technology
03
fig
04
fig
05
fig
Door
Sectional door with track
Door
Track
One piece door with
track
One piece door
without track
