GDO-7V1 SecuraLift® Owner Installation Instructions
Spare parts list
When ordering spare parts please quote the order
code Number to your installer/dealer
Item/description order code
1 Base plate sub assembly 02152
2 Bush 127id 18 04261
3 Ac motor it 0.24Kw 14423
4 Sel-lock pin spring acp m4x20 02590
5 Label thermally protected 13620
6 Cover protection 13790
7 Hex nut w/int tooth washer m5 10881
8 Label 240v 60 watt gdo-2 13630
9 Motor bracket gdo-7 13776
10 Bush 127 17-10 04271
11 Bush id 10x10 04290
12 Worm 2520 2s-st 04932
13 Chopper wheel gdo-7 04951
14 Chopper clip 04960
15 Board housing sub assy 01586
16 Control board cb-18 v1 01020
17 Board shield 14053
18 Taptite screw ‘p’ m4x8 10580
19 Power cord 1.5M w 2pin+1 ring 14150
20 Easy access transmitter pack 01236
21 Controls lid 05108
22 Cord grip grommet sbr5-2 05605
23 Lamp holder ls 204-1 05761
24 Terminal block 500/02ds 2 pos 05421
25 Harness assy cb-7 (not shown) 14441
26 Cap polyfilm 0.1 Uf k x2 275 vac 07575
27 Terminal block shield 14056
28 Drive shaft q-c 04542
29 Helical gear 34209 04941
30 Sprocket 8t octagonal 04685
31 Cap motor 15.0 Uf 44o vac 3k hr 14402
32 Chain idle wheel 02962
33 Snap pin ssp 8 znu 31080 10720
34 Snap pin ssp 12 znu 31120 10730
35 Cable clamp acc-15 (3/16”) 11750
36 Globe 250v 60w 14120
37 Pan head screw w/washer m5x10 10281
Item/description order code
38 Pan serration head screw m4x12 10380
39 Pan head screw w/washer m4x10 10340
40 Pan head screw m3x14 10360
41 Internal tooth lock washer i.D.3 11150
42 Cover assy gdo-7 01599
43 Light diffuser 13902
44 Taptite screw ‘p’ black m3.5X6 10542
45 Pan head screw w/washer m4x8 10320
46 Chain joint link 02950
47 Shuttle assembly 00273
48 Secura ptx-4 & wall switch pack 01220
49 Transmitter grey buttons ptx-4 01210
50 Transmitter red buttons ptx-4 01211
51 Ptx holder 05196
52 Alkaline battery a23 12v 13030
53 Plastic wall plug pack 01479
54 Clevis pin diameter 8 02550
55 Pin 05790
56 Hex head screw m8x25 10110
57 Hex serration flange nut m8 10148
58 Wall bracket 02521
59 Door bracket 02511
60 Door bracket locator 02515
61 Support pipe cx assembly 00292
62 Chain 1/2”x1/8” (499 links) w/2 cl 03000
63 Tube 338605 13801
64 Index tube 338605 13811
65 Tube-insert 2970 13830
66 Bent arm 02800
67 Straight arm 02790
68 Ratchet timing assembly 01737
69 Sensor assembly 01689
70 Taptite screw ‘p’ m3x12 10553
71 Vibration isolator 02530
72 Pan head screw w/washer m4x10 10340
73 Shoulder screw 5-m4x9l 10601
74 Grommet 5.2X8.0X4.5 05604
