Owner Installation Instructions GDO-7V1 SecuraLift®
23
32
fig
33
fig
Final set up
23. Setting of courtesy light time
The preset courtesy light time on the door opener is 3
minutes. This time can be changed by the following:
1. Press in and hold both the Auto Close Time button
and Force Margin Set button (Fig. 32).
2. While holding in the two buttons, press the Plus (+)
button. Each press of the button will add 10 seconds
to the light time.
3. To decrease the time follow Step 1 and press the
Minus (-) button. Each press will deduct 10 seconds
from the light time.
4. To recall the factory set default light time press in
and hold together the Auto Close Time button, the
Force Margin Set button and the Set button for
about 2 seconds. Release all buttons, the factory set
default of 3 minutes will be recalled.
24. Setting the pet mode door
opening position.
The default PET (Pedestrian) position is factory preset
to a predetermined height. The PET mode status is
indicated by both the Open and Close Limit LED’s
being illuminated. The default position can be changed
by the following:
1. Make sure the door is in the closed position.
Press and hold the Plus (+) button for six (6) seconds
(Fig. 32), you should hear three beeps and the Open
and Close LEDs will flash rapidly.
2. Press the Plus (+) or Minus (-) button (Fig. 32) to
move the door to your required new pet open door
position.
3. Press the Set button (Fig. 32) to record the new
position.
The Pet mode is activated from a transmitter button
coded to that function. When activated the door drives
to the preset position from either above or below. If
the Pet button is pressed while the door is moving the
door will be stopped. If the Pet button is pressed when
the door is in the Pet position, then the door will be
closed. No auto close is enabled.
25. Installation of wall mounted
transmitter holder
1. Mount the holder in a location out of reach of
children and convenient to the customer. (Fig 33).
Make sure the door is visible from this location.
2. The transmitter can be easily clipped in and removed
from the holder as required.
3. To set the transmitter codes refer to Step 18 on Page
20.
26. Re-initializing the opener
To re-initialize the opener press and hold the Set
Button for two (2) seconds, the beeper will sound
once. The door will start to move and re-calculate
force margins. The door can move between the
open and close limit positions up to four (4) times
(depending on the position of the door and the
power up condition). A single beep will be heard
once the initialization is complete. The door is
now ready for use.
