Owner Installation Instructions GDO-7V1 SecuraLift®
25
Parameters
Door Status Indicators
Buttons Function
Operate Opens/Stops/Closes the door
Door code Codes a transmitter button for operate function
Light code Codes a transmitter button for light function
Door code & Minus (-) Codes a transmitter button for pet
(pedestrian function
Light code & Minus (-) Codes a transmitter button for vacation function
Force Margin Set & Plus (+) Increases the obstruction force margin setting
Force Margin Set & Minus (-) Decreases the obstruction force margin setting
Force Margin Set (then) Set Reloads the factory set default obstruction force
margin setting
Auto close time (then) Plus (+) Increases the auto close delay time
Auto Close Time (then) Minus (-) Decreases the auto close delay time
Auto Close Time (then) Set Reloads the factory set default auto close delay time
Force Margin Set & Auto Close Time (then) Plus (+) Each press of the open button increases the light time
by 10 secs.
Force Margin Set & Auto Close Time (then) Minus (-) Each press of the open button decreases the light time
by 10 secs.
Force Margin Set & Auto Close Time (then) Set Reloads the factory default light time
Minus (-) (for 6 secs.) Clears the door limits set positions. Limits then need
to be reset
Set & close (for 2 secs.) Enters pet (pedestrian) position mode
Set (then power on) & hold until all LEDs are off Deletes control parameters excluding transmitter
storage memory
Door Code (then power on) & hold until all LEDs
are off
Deletes all transmitter storage memory
Set & Door Code (the power on) and hold until all
LEDs are off
Deletes all control parameters and transmitter storage
memory.
Set Re-initialises the Opener to re-calculate force margin
