Automation Technology C2 Series Hardware Reference Manual

C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8 • 41
Examples of Output Frame Structure
1) Configuration with single AOI, single DC, disabled NDR mode and output of 6 profiles resulting to
a frame height of 6 rows:
ProfilesPerFrame=10
NumAOIs=1
EmableDC0= false,
EnableDC1=false
EnableDC2=true
NDRMode=”Off”
Row # Description Profile #
1 Data of DC2 readout from AOI1 1
2 Data of DC2 readout from AOI1 2
3 Data of DC2 readout from AOI1 3
4 Data of DC2 readout from AOI1 4
5 Data of DC2 readout from AOI1 5
6 Data of DC2 readout from AOI1 6
