42 • C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8
2) Configuration with two AOIs, two DCs, disabled NDR mode and output of 5 profiles resulting to
frame height of 20 rows:
ProfilesPerFrame=5
NumAOIs=2
EmableDC0= true,
EnableDC1=false
EnableDC2=true
NDRMode=”Off”
Row # Description Profile #
1 Data of DC0 readout from AOI1 1
2 Data of DC2 readout from AOI1
3 Data of DC0 readout from AOI2
4 Data of DC2 readout from AOI2
5 Data of DC0 readout from AOI1 2
6 Data of DC2 readout from AOI1
7 Data of DC0 readout from AOI2
8 Data of DC2 readout from AOI2
9 Data of DC0 readout from AOI1 3
10 Data of DC2 readout from AOI1
11 Data of DC0 readout from AOI2
12 Data of DC2 readout from AOI2
13 Data of DC0 readout from AOI1 4
14 Data of DC2 readout from AOI1
15 Data of DC0 readout from AOI2
16 Data of DC2 readout from AOI2
17 Data of DC0 readout from AOI1 5
18 Data of DC2 readout from AOI1
19 Data of DC0 readout from AOI2
20 Data of DC2 readout from AOI2
