Automation Technology C2 Series Hardware Reference Manual

C2-2040(HS)-GigE Camera Hardware Reference Manual Rev. 1.8 • 43
3) Configuration with single AOI, single DC, NDR mode with two NDR frames and output of 3 profiles
resulting to a frame height of 6 rows:
ProfilesPerFrame=6
NumAOIs=1
EmableDC0= false,
EnableDC1=false
EnableDC2=true
NDRMode=”On”
NumberOfNDRFrames=2
Row # Description Profile #
1 Data of DC2 extracted from NDR1, readout from AOI1 1
2 Data of DC2 extracted from NDR2, readout from AOI1
3 Data of DC2 extracted from NDR1, readout from AOI1 2
4 Data of DC2 extracted from NDR2, readout from AOI1
5 Data of DC2 extracted from NDR1, readout from AOI1 3
6 Data of DC2 extracted from NDR2, readout from AOI1
