Before you begin...
It is recommended that the following items be available to make this short step-by-step
introduction to the CLICK PLUS PLC go smoothly.
CLICK PLUS PLC unit
CLICK
Programming Software
C0-PGMSW
Screwdriver
TW-SD-MSL-2
PC Programming Cable
D2-DSCBL
USB A to USB micro B
Programming
Cable Assembly
USB-CBL-AMICB6
PC Running
Windows
Hookup Wire
or
USB or Free download @
http://support.automationdirect.com/
products/clickplcs.html
AC Power Cord
Other 24VDC Power Supply
Example: PSP24-60S
CLICK 24VDC Power Supply
C0-00AC or C0-01AC
PC requires RS-232 port.
Wire Strippers
DN-WS
Not available from ADC.
Not available from ADC.
Based on your CLICK PLUS PLC,
One of the cables shown below:
Ethernet Cat5 Cable
CLICK PLUS PLC Hardware User Manual, 1st Edition, Rev. K – C2-USER-M
1-4
Chapter 1: Getting Started
