Autonics LE4S Series User Manual

N-32
LE4S Series
[Figure1] [Figure2] [Figure3] [Figure4] [Figure5]
Setting Time Change
● Backlight ON/OFF setting
● Key Lock setting
● Output operation mode: OND, OND
Ⅰ
, OND
Ⅱ
, INT, INT
Ⅰ
, OFF D
(LE4SA does not have no OND
Ⅰ
, INT
Ⅰ
, OFF D.)
3) Press to complete Backlight ON/OFF setting and move to the next mode.
4) If pressing for 3 sec in any function setting mode, it will return to Run mode.
Please set operation time according to following instruction as the setting is di󰀨erent depending on the output operation
mode.
1) Press in RUN mode, time set digits will ash. [Figure 1]
2) Change setting time by using or . [Figure 2,3,4]
- : Shift the setting digits.
- : Shift the ashing position value. As press once, it will increase by 1digit,
number will increase faster by press for over 2 sec
3) When the setting is completed, it will be stored and return to RUN mode by pressing [Figure 5]
Display Function
lOFF
Turns o󰀨 the key Lock mode.
LOc1
cannot be used.
LOc2
, cannot be used.
LOc3
, , cannot be used.
Turns o󰀨
the Lock mode.
Blank
cannot be used.
,
cannot be used.
, ,
cannot be used.
[Figure6]
※
Factory default
[Figure7]
※
Factory default
1) In function setting mode, if it enters into Backlight ON/OFF setting mode, the characters
will be displayed as shown in the [Figure 6].
2) Select Backlight
ON
or
OFF
using , .
1) In function setting mode, if it enters into Key Lock setting mode, the characters will be
displayed as shown in the [Figure 7].
2) Select
lOFF
,
LOc1
,
LOc2
or
LOc3
using , .
3) Press to complete key lock setting and move to the next mode.
4) If pressing for 3 sec in any function setting mode, it will return to Run mode.
※
Factory default for LE4S is
lOFF
and Factory default for LE4SA is
LOc1
.
※
Key Lock function
