Autonics LE4S Series User Manual

N-34
LE4S Series
LE4S Output Operation Mode
T = Setting time, T > Ta
※
Initial status: UP mode-display value is "0", output is "OFF". DOWN mode-display value is "setting time", output is "OFF".
T > Ta
Ton, To󰀨 > Ta
T > Ta
T > Ta
Ton, To󰀨 > Ta
T = set time
T = set time
Tout = output time
T = set time
Ton, To󰀨 = set time
Enables to set Ton and
To󰀨 time di󰀨erently.
Ton, To󰀨 = set time
Enables to set Ton and
To󰀨 time di󰀨erently.
Mode
Time chart Operation
[
OND
]
POWER
START
RESET
RELAY OUT
Setting time
Setting time
0
0
UP
DOWN
T T
①
② ③
④
TTa
POWER
START
RELAY
OUT
T
OND
ON Delay
1. Timing operation starts when START signal is ON at status of power on.
2. Output will be ON when timing operation is progressed up to the setting time. Display value will be
HOLD. (
①
position)
3. When RESET signal is ON, display value and output will be reset. (
②
position)
4. If RESET signal is OFF while START signal is ON,“STEP 1”will be restarted. (
③
position)
5. When START signal is OFF, display value and output will be reset. (
④
position)
[
ONd1
]
POWER
START
RESET
RELAY OUT
Setting time
Setting time
0
0
UP
DOWN
T T
①
②
③
TTa
POWER
START
RESET
RELAY
OUT
T
OND
Ⅰ
ON Delay 1
1. Timing operation starts when START signal is ON at status of power on.
2. Output will be ON when timing operation is progressed up to the setting time. Display value will be
HOLD. (
①
position)
3. Even though START signal is applied repeatedly, only the initial signal is recognized. (
②
position)
4. When RESET signal is ON, display value and output will be reset. (
③
position)
[
ONd2
]
POWER
START
RESET
RELAY OUT
Setting time
Setting time
0
0
UP
DOWN
T T
①
②
TTa Ta
T
Tout
POWER
START
RELAY
OUT
OND
Ⅱ
ON Delay 2
(One-shot output)
1. Timing operation starts when START signal is ON at status of power on.
2. Time limit output will be ON and goes OFF during Tout setting time when timing operation is progressed
up to the setting time. Display value will be HOLD. (
①
position)
3. When RESET signal is ON, display value and output will be reset.
4. If START signal is applied while time is progressing, Timing operation will be reset and started again. (
②
position)
5. Tout setting range: 0.01 sec to 99.99 sec
[
FLK
]
POWER
START
RESET
RELAY OUT
To󰀨
To󰀨
Ton
Ton
0
0
UP
DOWN
To󰀨 To󰀨 To󰀨 To󰀨 To󰀨Ton Ton
Ton
Ta Ta Ta
To󰀨 Ton To󰀨 Ton
POWER
START
RELAY
OUT
FK
Flicker
(To󰀨 operation
precedes)
1. If START signal is ON, output will be repeatedly OFF during To󰀨 setting time and will be OFF during Ton
setting time when power is ON.
2. When RESET signal is ON, display value and output will be reset.
3. If RESET signal is OFF when START signal is ON, “STEP 1” will be restarted.
4. When START signal is OFF, display value and output will be reset.
5. It is able to set each To󰀨 time and Ton time separately. In [ ] mode, timing operation starts with To󰀨.
[
FLk1
]
POWER
START
RESET
RELAY OUT
To󰀨
To󰀨
Ton
Ton
0
0
UP
DOWN
①
To󰀨
To󰀨
To󰀨To n Ton Ton Ton
Ton
Ta Ta Ta
POWER
START
RELAY
OUT
Ton To󰀨 Ton
FK.
Ⅰ
Flicker 1
(Ton operation
precedes)
1. IF START signal is ON, output will be repeatedly ON during Ton setting time and will be OFF during To󰀨
setting time when power is ON.
2. Even though START signal is applied repeatedly, only the initial signal is recognized. (
①
position)
3. When START signal is ON, display value and output will be reset. If START signal is ON, it will be
restarted.
4. It is able to set each To󰀨 time and Ton time separately. In [ ] mode, timing operation starts with Ton.

Autonics LE4S Series Specifications

General

Brand	Autonics
Model	LE4S Series
Category	Timer
Language	English
