6
Voltage Test Result
How to use: When the probe clip (auxiliary ground lead) is
connected to the ground wire, the probe will automatically
enter the voltage display mode when a voltage signal detected
on the probe Tip, it will display the test voltage.
As shown in the figure, “BATT” means that the battery supply
voltage is 9.9V, and “VDC” is the current test DC voltage value
10.0V.
●
●
This probe adopts a 2.4-inch large color screen and 9-grid
interface design, with clear display, simple operation and quick in
use. You can select working mode through the navigation buttons
and press OK to enter.
WORKING MODE
The main test functions of this mode: voltage test, resistance test,
Positive / negative test. (display as VDC, OHM). It is mainly used
for quick test without switching between different test modes.
Automatically recognize the measured signal and display values
of voltage or OHMs.
Smart test
