Autool BT280 User Manual

11
Display Value
VDC: Detected Voltage
AMP: Detected Current
VCC: Power Supply Voltage
●
●
●
Activation Type
“MOMENT” Mode:
Press “Right” button to select the
activation mode to MOMENT mode.
Press and hold the “UP” / “Down”
button to perform the power supply,
Release “UP” / “Down” button to stop.
●
“LATCH” Mode:
Press “Right” button to select the
activation mode to LATCH mode.
Press the “UP” / “Down” button to
perform the power supply, Press “UP”
/ “Down” button again to stop.
●
“PULSE” Mode:
Press “Right” button to select the
activation mode to PULSE mode.
Press the “UP” / “Down” button to
perform the power supply, It will
automatically supply power cycles in 1
second.
●
Off
Press
ON
Release
OFF
On
Off
Press &
Release
ON
Press &
Release
OFF
On
.5 sec .5 sec
.5 sec
Off
Press &
Release
START
Press &
Release
STOP
On
