仪表供了5V信号线路和12V信号线路的检测能力当连接到5V
信号线上,K线上的信号为5V信号当连到12V信号线上,K线
上的信号为12V信号。
仪表置可测K线率为1200/2400/4800/9600/10400/
19200/38400/57600/115200如果需要的波特率
,进
能项,示如下图
54
[F1]键清除当前显示数据
[HOLD]当前显,在 ,按 [上下]
以向前向后翻阅接收到的数据。
接收状态下按[左右方向键],可
K 线数据 BPS 10400
<F1>清除 <Fn><LEFT><RIGHT>设置速度
82 19 F0 A8 01 34 BF FO 19 E8
01 00 04 FF FF FF FF 01 04 FF
00 00 00 02 02 FF FF 0C 02 FF
FF 0D 01 FF 1C 01 FF 1F 02 FF
FF 20 04 FF FF FF FF 21 02 FF
FF 30 01 FF 31 02 FF FF 40 04
C01 - K
C01 -
GND
C01
