EQUIPMENT INSTALLATION 21
Rev A
Figure 12
Regenerant Tank Check Valve (not provided)*
* Furnished as an option from conditioner system manufacturer.
Electrical Connection
All 700 Series controllers operate on 12-volt alternating current power
supply. This requires use of the supplied AC adapter. A variety of AC
adapters are available for different applications. These AC adapters are
available from your supplier. They include:
AC Adapter
Input
Voltage
Application Part Number
Standard wall-mount
AC adapter
120V 60Hz Standard indoor
application
1000811
Outdoor rated AC
adapter
120V 60Hz UL listed for
outdoor
installations
1235448
International option AC
adapters
Varies
based on
country
Standard indoor
application
See Parts Lists
Section
