30 DISPLAY ICONS 700 CONTROLLER
Rev A
KEYPAD — Buttons
1. DOWN arrow. Generally used to scroll down or increment through a
group of choices.
2. SET. Used to accept a setting that normally becomes stored in
memory. Also used together with the arrow buttons.
3. UP arrow. Generally used to scroll up or increment through a group of
choices.
4. Regenerate. Used to command the controller to regenerate. Also used
to change the lock mode.
Programming Conventions
The 700 Series controller is programmed using the buttons on the keypad.
The programming instructions will be described two ways whenever a
section has keypad input.
First, a table shows simplified instructions. Second, text follows that
describes the action. In each table:
"Action" lists the event or action desired.
"Keys" are listed as:
UP for up arrow
DOWN for down arrow
SET for set
REGEN for regeneration
21
3
4
NOTE: If a button is not pushed for thirty seconds, the controller returns to
normal operation mode. Pushing the regenerate button immediately returns
the controller to normal operation.
