PARTS AND ACCESSORIES 59
Rev A
255 Valve Parts List
*Not Shown
Code
Part
No. Description Qty. Code
Part
No. Description Qty.
1 1244650 255 Valve Assembly, w/o Flow Controls 1 16 1000269 Injector Cap with O-Ring 1
2 1033784 255 Tank Adapter New Style 1 17 Drain Control Assembly with O-Ring 1
3 1010429 O-Ring BN 1 1000209 No. 7 (1.3 gpm; 4.9 Lpm)
4 1010428 O-Ring EP 1000210 No. 8 (1.7 gpm; 6.4 Lpm)
5 1235340 Top Plate, 255 Valve, Logix Series 1 1000211 No. 9 (2.2 gpm; 8.3 Lpm)
Controller 1000212 No. 10 (2.7 gpm; 10.2 Lpm)
6 1235341 Spring, One Piece, 255 Valve 1 1002130 No. 12 (3.9 gpm; 14.76 Lpm)
7 1236246* Cover, Valve, 255/Performa, Logix 1 1000214 No. 13 (4.5 gpm; 17 Lpm)
Series Controller 1000215 No. 14 (5.3 gpm; 20 Lpm)
8 1001404 O-Ring Group: Tank Adapter 1 18A 1000222 Regenerant Refill Controller, No Ball, 0.33 gal. 1
9 1040459 O-Ring Group: Piping Boss 1 18B 1243510 Regenerant Refill Controller
10 1001986 13/16 inch Rubber Insert (Optional) 1 19 Air Check Kit 1
* 1000250 Valve Disk Kit - Standard 1 1032416 Air Check Kit 3/8-inch male
* 1239760 Blending Valve Kit 900/700 Series 1 1032417 Air Check Kit 1/4-inch male
11 Locking Bar 1 20 1235373 Module, Sensor, Photo Interrupter 1
1031402 English Language Locking Bar 21 1235361 Motor w/Spacer, Pinion, and Cable, 1
1031403 French Language Locking Bar 700 Series Controller, 12 V, 50/60 Hz
1031404 German Language Locking Bar 22 1030502 Ball, Flow Control 1
1031405 Italian Language Locking/Bar * 1033066 New to Old Style Aircheck Adapter 1
1031406 Japanese Language Locking Bar 23 1235446 Turbine Cable 1
1031407 Spanish Language Locking Bar * 1233187 Motor Locking Pin
1006093 Locking Bar Screw - No. 8-9/16 inch * 1268102 No Salt Detector/Refill Control
12 Camshaft Options 1 * 1242411 Extension Cord for Cabinet
1235353 Cam 255/70 Series Valve, STD, * 1239711 Service Kit, Front Mount, 0.1 amp
Black * 1239752 Service Kit, Front Mount, 5 amp
13 1235269 Motor/Optical Cable Assembly, 700 1 * 1239753 Service Kit, Top Plate Mount, 0.1 amp
Series Controller * 1239754 Service Kit, Top Plate Mount, 5 amp
14 1000226 Screen/Cap Assembly w/ O-Ring 1
15 Injector (High Efficiency) Options 1
1035730 “E” Injector (HIgh Efficiency) - Yellow
(6-inch tank)
1035731 “F” Injector (High Efficiency) - Peach
(7-inch tank)
1035732 “G” Injector (High Efficiency) - Tan
(8-inch tank)
1035733 “H” Injector (High Efficiency) - Lt Purple
(9-inch tank)
1035734 “J” Injector (High Efficiency) - Lt Blue
(10-inch tank)
1035735 “K” Injector (High Efficiency) - Pink
(12-inch tank)
1035736 “L” Injector (High Efficiency) - Orange
(13 - 14-inch tank)
To Next Page
