60 PARTS AND ACCESSORIES

Rev A

255 Valve Parts List (Continued)

*Not Shown

Code

Part

No. Description Qty. Code

Part

No. Description Qty.

* Piping Boss Tube Adapter Kits

Piping Boss Kit (includes hardware): * 1001606 3/4-inch Copper Tube Adapter Kit 1

1040277 3/4-inch NPT, Brass 3/8-inch NPT Drain * 1001670 1-inch Copper Tube Adapter Kit 1

1040278 1-inch NPT, Brass 1/2-inch NPT Drain * 1001608 22-mm Copper Tube Adapter Kit 1

1040281 3/4-inch BSPT, Brass 3/8-inch BSPT * 1001613 3/4-inch CPVC Tube Adapter Kit 1

Drain * 1001614 1-inch CPVC Tube Adapter Kit 1

1040282 1-inch BSPT, Brass 1/2-inch BSPT Drain * 1001615 25-mm CPVC Tube Adapter Kit 1

1040279 3/4-inch NPT, Noryl 1/2-inch NPT Drain * 1001769 3/4-inch NPT Plastic Pipe Adapter Kit 1

1040280 1-inch NPT, Noryl 1/2-inch NPT Drain * 1001603 1-inch NPT Plastic Pipe Adapter Kit 1

1040283 3/4-inch BSPT, Noryl 1/2-inch BSPT * 1001604 3/4-inch BSPT Plastic Pipe Adapter Kit 1

Drain * 1001605 1-inch BSPT Plastic Pipe Adapter Kit 1

1040284 1-inch BSPT, Noryl 1/2-inch BSPT Drain * 1001611 3/4-inch BSPT Brass Pipe Adapter Kit 1

* 1040339 Piping Boss Installation Kit 1 * 1001610 1-inch NPT Brass Pipe Adapter Kit 1

* Meter Adapter * 1001612 1-inch BSPT Brass Pipe Adapter Kit 1

1032350 Kit, Meter Adapter 1

1032351 Meter Install Kit 1

* Bypass Valve

1040769 Bypass Body Assembly with Install Kit 1

1040524 Bypass Installation Kit 1
