Autronica AutroGuard V-530 - Page 32

Technical Specifications
Technical Handbook, AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339, Revision 1, 2020-06-29,
Autronica Fire and Security
Page 26
Tone 1 - Dutch slow whoop 500-1200
High volume: 93 dB(A) @ 1 m max. / 78 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
79.44
80.94
1.5
84.44
86.14
1.7
45
78.04
79.54
1.5
85.04
86.64
1.6
75
91.44
93.04
1.6
80.34
81.54
1.2
105
86.64
88.14
1.5
82.04
83.74
1.7
135
81.04
82.54
1.5
84.74
86.34
1.6
165
81.64
83.24
1.6
85.94
87.54
1.6
Low volume: 83 dB(A) @ 1 m max. / 70 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
71.24
71.34
0.1
75.64
75.74
0.1
45
69.74
70.14
0.4
76.24
76.24
0
75
83.14
83.14
0
70.94
71.74
0.8
105
78.14
78.44
0.3
73.74
73.44
-0.3
135
72.64
72.64
0
75.64
75.64
0
165
73.34
73.34
0
76.94
77.04
0.1
Tone 2 - Alternating 730 & 915
High volume: 90 dB(A) @ 1 m max. / 73 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
78.44
78.94
0.5
80.14
80.74
0.6
45
72.74
72.74
0
82.24
82.74
0.5
75
89.34
89.84
0.5
75.54
75.64
0.1
105
85.64
86.14
0.5
77.64
78.04
0.4
135
78.24
78.84
0.6
80.74
81.24
0.5
165
80.44
80.94
0.5
81.74
82.24
0.5
Low volume: 82 dB(A) @ 1 m max. / 64 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
70.94
70.94
0
73.54
73.54
0
45
64.64
64.64
0
75.14
74.94
-0.2
75
82.44
82.44
0
68.94
68.94
0
105
78.94
79.04
0.1
71.24
71.04
-0.2
135
72.34
72.24
-0.1
73.94
73.94
0
165
73.14
73.14
0
74.44
74.44
0
