Overview
HDMI
Connect to HDMI
devices via HDMI
cables to transmit
audio and video.
PC AUDIO
Connect to the
audio output of
a computer.
PC-RGB (VGA)
Connect to a
computer
Component Video
Connect to A/V devices
using component video
cables. Match the colors on
your cable connections with
the colors on the jacks.
TUNER
Connect an antenna
or cable for TV
reception.
S-VIDEO
Connect S-Video
signal from a
camcorder or VCR.
AV-IN (Composite)
Connect A/V composite video
and audio signal (R/L) cables.
Match the colors on your
cable connections with the
colors on the jacks.
SERVICE
For service
personnel use
only.
