AUX air conditioner service manual
138
Detailed part list of ASW-H24B4/HS indoor unit
No Chinese Name Name Material Number
1 过滤网组件 Filter 2
2 螺钉盖 Screw cover 3
3 中框组件 Medium frame 1
4 导风门 Horizontal air blade 1
5 导风叶片 Vertical air blade 14
6 导风架 Air blade holder 1
7 蒸发器左支架 Left plastic crutch for evaporator 1
8 蒸发器总成 Evaporator 1
9 橡胶轴承座 Rubber bearing 1
10 贯流风叶 Indoor fan 1
11 底座组件 Chassis 1
12 挂板组件 Mounting plate 1
13 管路压攀 Pipe clamp 1
14 塑封电机 Indoor fan motor 1
15 电控盒 Electric controller box 1
16 变压器 Transformer 1
17 端子板 Terminal board 1
18 主控板 A Main PCB 1
19 步进电机组件 Step motor 1
20 电控盒盖 Cover for electric controller box 1
21 指示灯座 Indication lamp holder 1
22 显示板 Display board 1
23 面板组件 Panel 1
24 显示灯板 Display board cover 1
