Detailed part list of ASF-H41A5/C outdoor unit
No Chinese Name Name Material Number
1 面板网罩 Defense net of front panel 1
2 面板 Front panel 1
3 底盘组件 Chassis 1
4 储液桶 Liquid collector of compressor 1
5 压缩机 Compressor 1
6 阀板 Valve plate 1
7 截止阀 Dg8 Liquid valve Dg8 1
8 截止阀 Dg16 Gas valve Dg16 1
9 右侧板 Right-side plate 1
10 电器盖板 Cover for electric wiring 1
11 四通阀组件 Four-way valve assembly 1
12 电器架 Electrical holding plate 1
13 主控板 Controller 1
14 端子板 Terminal board 1
15 交流接触器 AC connector 1
16 风机电容 Fan motor capacitor 1
17 毛细管组件 Capillary assembly 1
18 冷凝器组件 Condenser assembly 1
19 顶盖板 Top cover plate 1
20 左侧支撑板 Left-side panel supporting-plate 1
21 电机架组件 Motor bracket 1
22 电机 Fan motor 1
23 贯流风叶 Indoor fan 1
24 挖手 Handle 1
