AUX H Series User Manual

AUX air conditioner service manual
91
Max. input power W 2700 3000 3450 3800
Max input current A 13.6 15.1 17.4 19
Refrigerant R22 R22 R22 R22
The model of
Plastic-sealed
motor
YDK30-8B YDK30-8B YDK52-8A YDK68-8A
Rotate speed
of the motor
r/min
400/350/300 400/350/300 480/440/360 540/480/440
Output power
W
30 30 52 68
Air blade type
Centrifugal
blade
Centrifugal
blade
Centrifugal
blade
Centrifugal
blade
Specification
of the air
blade
(dia.-length
mm)
350-152 350-152 350-152 350-152
Model of
step-motor
49TDY/49TDJ 49TDY/49TDJ 49TDY/49TDJ 49TDY/49TDJ
Power W 3 3 3 3
Fuse A 3.5 3.5 3.5 3.5
Noise dB(A) 38~42 38~42 41~48 42~49
Dimension cm
(L×W×H)
30×48.3×170.5
30×48.3×170.
5
30×48.3×170.5 30×48.3×170.5
Net weight kg 35 35 35 37
Specification
of the electric
cable
3×1.5mm
2
3×1.5mm
2
3×3.0mm
2
3×3.0mm
2
Indoor
unit
Specification
of the electric
connecting
cable
3×1.5mm
2
3×1.5mm
2
3×2.5mm
2
2×0.75mm
2
3×2.5mm
2
2×0.75mm
2
Total unit
ASF-18A4/
C(Z)
ASF-18B4/
C(Z、P)
ASF-24A4/
C(Z、P)
ASF-24B4/
C(Z、P)
Indoor unit
ASF-18A4/C(
Z)
ASF-18B4/
C(Z、P)
ASF-24A4/
C(Z、P)
ASF-24B4/
C(Z、P)
model
items
Outdoor unit AS-18A4/1 AS-18B4 AS-24A4 AS-24B4
Motor model YDK40-6 YDK40-6 YDK68-6A YDK68-6A
Outdoor
unit
Rotate speed of
motor r/min
850 850 850 850

AUX H Series Specifications

General

Brand	AUX
Model	H Series
Category	Air Conditioner
Language	English
