AUX H Series User Manual

AUX air conditioner service manual
94
Net weight kg 38 37 58 58
Specification
of the electric
cable
5×2.5mm
2
5×2.5mm
2
5×2.5mm
2
5×2.5mm
2
Specification
of the electric
source
connecting
cable
5×1.5mm
2
5×1.5mm
2
5×1.5mm
2
5×1.5mm
2
Total unit
ASF-H24B5
/B
ASF-24B5/B ASF-H41A5/C
ASF-41A5/
C
Indoor unit
ASF-H24B5
/B
ASF-24B5/B ASF-H41A5/C
ASF-41A5/
C
model
items
Outdoor unit
AS-H24B5/
B
AS-24B5/B AS-H41A5/C AS-41A5/C
Motor model YDK68-6A YDK68-6A
YDK150-60-4
20
YDK150-60
-420
Rotate speed of
motor r/min
850 850 820 820
Power of motor W 68 68 150 150
Motor capacitor 4.0 4.0 6 6
Specification of air
blade
(diameter mm)
440 440 490×125 490×125
Refrigerant charge
kg
2 2 3 3
Refrigerant control / / / /
Working
temperature of
compressor
-7~43 -7~43 -7~43 -7~43
Protection device
Inner
installed
Inner installed
Inner +low
pressure
protection+
exhaust
temperature
protection
Inner +low
pressure
protection+
exhaust
temperature
protection
Noise dB(A) 57 57 83 83
Dimension cm
L×W×H)
37.8×86.7×6
9.5
37.8×86.7×69.
5
33×90×86 33×90×86
Net weight kg 54 53 85 85
Outdoor
unit
Installation size
mm
606×354 606×354 585×376 585×376
