26
600 Series
Dashboard
On the dashoard on the right side of the driver’s seat are mounted
gauges, indicators and switches which help you to control the loader.
Operating instructions
3
6
4
7
8
1
20
17
9
12
16
5
18
14
19
8
17
20
19
1
7
14
13
18
6
3
4
5
9
16
Cab LX /DLX
ROPS
Indicator lights, gauges and switches on the dashboard
Ref. Symbol Color Remarks
1
Red
Hydraulic oil cooler fan fuse
Hydraulic oil cooler malfunction.
See page 58
2
Red
Load sensor indicator
Warning: Too heavy load is being
lifted. See page 23
3
Yellow
Boom oating on
(optional equipment) Boom oating
See page 30
4
Green Seat heater on
5
Yellow Glow plug indicator
6
Blue
High beam headlights on
Road trafc light kit only
7
Red
Oil pressure low warning
Stop engine immediately to avoid
severe engine damage. Contact service.
8
Green
Work lights on
Work light switch at lower part of
dashboard
9
Red
Charge indicator
Alternator low charging voltage
warning. Contact service.
10
Green
Turn signal indicator
Road trafc light kit only
Cab LX/DLX dashboard only
Ref Gauge
11 Fuel gauge
12 Thermometer - Engine coolant temperature
13
Tachometer - Engine RPM
14
Hour meter
15
Ignition switch - See page 35
Ref. Symbol Switch
16
Signal horn
17
Seat heater switch
18
Work light switch
19
Boom oating switch (optional extra)
20
LOCK
Drive release valve switch See page 29
10
11
11
12
13
15
15
2
2
