DWBS Testing
4-10 Issue 6 September 2001
Figure 4-7. Connections for WT Firmware Download (9630 Series WT)
NOTE:
Refer to the “TN789 RC Circuit Pack Pin Configuration” table in the previous
chapter for details on RC pin connections with the 902A download cable.
D8W Cord
103 Connector Block
Data
6-Foot
Data
Connector
At the
Wall Field
Modular
Connector
Wireless
Ter mi nal
RC
Circuit
Pack
9630
Connectors
Wireless Terminal
Download Cable
