Avaya Definity - Using Keys to Download WT Firmware

Procedure: WT Firmware Download and Connection
Issue 6 September 2001
4-11
Using Keys to Download WT Firmware
To perform a WT firmware download by using keys, activate the appropriate keys
according to the following directions.
For a 9601 WT, do the following:
1. Insert the download cable from the RC into the side of the WT.
2. Press .
3. Press .
4. Press the Info soft key.
5. Press .
6. Press the center soft key (not labeled) twice.
7. Press .
8. Press again.
9. Press the FW soft key.
10. Press the FromRC soft key.
11. For “Erase Flash,” select Yes. Once you do this, “Loading........” appears on
the screen. As the load progresses, a series of stars (****) builds across the
screen. When the loading is completed, the WT beeps and resets.
12. Remove the cable.
For a 9630 Series WT, do the following:
1. Insert the download cable from the RC into the bottom of the WT.
2. Press .
3. Press four times.
4. Press the More soft key twice.
5. Press the FW soft key twice.
6. Press the From RC soft key. Once you do this, “Loading........” appears on
the screen. As the load progresses, a series of stars (****) builds across the
screen. When the loading is completed, the WT beeps and resets.
NOTE:
If the firmware version on the RC is older than the firmware on the
WT, the following question appears: “RC FW Older Than Load Old
FW?” Press the accompanying Yes or No soft key, as appropriate.
7. Remove the cable.
At this point, the WT should display icons and is ready for use.
Menu
Next
Prev
Next
Next
Menu
Next
