DWBS Components
The following table lists the DWBS components along with the appropriate
apparatus code and comcode for each component.
Table 3-1. DWBS Components and Related Information
Description Apparatus Code Comcode
10 meg Flash Card L-15 card flash 10 meg 108-478-405
16 meg simms chip 16 meg DRAM chip 407-701-747
48v power supply 1151A1 (without battery backup) 107-212-952
48v power supply 1151A1 (new) 108-212-952
48v power supply 1151A2 (with battery backup) 108-212-960
48v power supply MSP-1 (MD) 107-915-514
9630 Series WT and
battery
108-272-477
9630 Series WT (textured)
Battery charger with power
supply
50A battery charger 108-386-921
Battery charger with power
supply (for CALA)
50B battery charger 108-398-074
Battery pack (textured) 4B-003 battery pack 108-272-485
CAU bracket
----- Model 1
----- Model 2
----- Model 3
CAU outdoor 559B circuit module
559C circuit module
108-313-677
Dipole CAU (DCAU) indoor 559D circuit module 108-339-003
Coaxial cable (100-foot
nominal)
coaxial cable Rg59 847-565-132
Control unit (WFB) with
internal antenna
119A1 control unit (special
order)
108-038-100
Control unit (WFB) without
internal antenna
119A control unit 107-582-405
Download cable (RC to
WT)
902A cable 108-369-315
