DWBS Testing
4-16 Issue 6 September 2001
a. Press .
b. Press four times.
c. Press the More soft key.
3. Upon completing your walk-through, if you have encountered any
problems, refer to the DWBS Maintenance document for further
investigation.
Procedure: Verifying Operative
Cell IDs
This procedure verifies that all the cells in the wireless configuration are “up” and
providing coverage.
NOTE:
Cell IDs for the 9630 Series WTs update dynamically. Therefore, the
following procedure is not required for 9630 Series WTs.
1. Move the 9601 WT battery away from its set position slightly; then reinsert
it.
2. For a 9601 WT, using the installation map as a guide, step into the first cell
to be checked, and position yourself close to the CAU (or to the WFB, if no
CAUs are present) for the particular cell. Obtain the cell ID by executing the
following key sequence on the 9601 WT:
a. Press .
b. Press .
c. Press the Info soft key.
d. Press to display the cell ID.
3. Confirm that the cell ID is displayed. If the cell ID is displayed, repeat
Step 1 for all the cells in the configuration. If there is no cell ID displayed,
use the following table:
If... Then...
Unit is a CAU Go to Step 3
Unit is a WFB Go to Step 4
