Local Administrative Options
40 9600 Series SIP IP Telephones Release 1.0 Installation and Maintenance Guide
1. When you select VIEW from the Admin Procedures Screen, the following text displays:
2. Use the navigation arrows to scroll through the viewable information.
3. Press Back at any time to return to the Admin Procedures screen.
Static Addressing screen Description and (System Value)
Model
Application File
Boot File
Group
MAC
Protocol
Phone SN
PWB SN
PWB comcode
Telephone Model, e.g., 9630
The “big app” filename.
The "little app" filename
Three digit GROUP value
MAC Address
Signaling protocol in effect, e.g., SIP
Telephone Serial Number
Printed Wiring Board (circuit board) Serial
Number (may not apply to all phones)
Software-readable PWB serial number and
comcode (may not apply to all phones)
