AVer TR333V2 - RS-422 Connection Details

12
1 8
 RS-422
[Note] Use cat5e splitter for multi-camera connection.
Cat5e splitter pin assignment:
1
234
5
678
1
234
5
678
1
234
5
678
Camera
Camera/Joystick
Camera/Joystick
RS-422 Pin
No.
Pin
No.
Pin
1
TX-
5
TX+
2
TX+
6
RX+
3
RX-
7
RX-
4
TX-
8
RX+
