Zone Mode
Set up the block areas for the camera to detect the presenter and track the presenter when the
presenter appears within the pre-configured areas (preset areas).
1. To configure the preset areas:
a. Select the number of blocks (2 Blocks, 3 Blocks or 4 Blocks) you want to configure for the
preset areas. Up to 4 preset areas can be configured.
b. Select a preset number from the drop-down list (Preset 6 ~ 9).
c. Use , , , , and to move the camera to the desired position.
d. Click Save to save the position to the selected preset number. A preset thumbnail will be
displayed below the preview window.
e. Repeat the steps to set up more preset areas.
[Note] To ensure smooth transition while tracking the presenter, please overlap the set up preset
areas. Do not separate the preset areas.
6
7 8
Ensure to overlap the preset areas
6
7 8
Do not separate the preset areas
