9
Model E1010 Indicator User’s Manual
Menu Mode
The E1010 has a User menu which you can use to do the following:
• Audit the number of configurations and calibrations performed
• See software information
• Display test
• Button test
• Serial port test
1. Access the User menu by pressing and holding the ESC key for 3-5
seconds.
PASS_ is displayed.
2. Key in the User menu password = 111 and press the ENTER key.
Figure 2 shows a flowchart of the User menu items. Use the keys shown
in the dotted box in Figure 2 to navigate through the menu and choose
the items you want.
Figure 2
User menu flowchart
Specific instructions on the User menu appear in the section Indicator
Diagnostics later in the manual.
User menu password is 111.
You must key in the password
within 10 seconds or the
display returns to normal
operation mode.
