Avid Technology Fast Track C400 - Front Panel Features

Fast Track C400 User Guide8
Fast Track C400 Front Panel Features
Figure 3 identifies each port on the front panel of the Fast Track C400.
The Fast Track C400 front panel provides the
following:
Instrument Inputs
These 1/4-inch inputs are for connecting an
electric guitar, bass, or other instrument-level
signal. The levels for these inputs is controlled
by the corresponding Input Gain knobs on the
top panel.
Headphone Output
Use the Headphone Output to connect stereo
headphones with a 1/4-inch stereo connector.
The level for this output is controlled by the
Headphone Volume knob on the top panel.
Figure 3. Fast Track C400 front panel
Instrument Inputs
Headphone Output
