Fast Track C400 User Guide12
Connecting Audio Inputs
This section describes the analog inputs avail-
able on Fast Track C400. For information about
connecting specific audio sources, see “Con-
necting a Microphone” on page 13, and “Con-
necting Instruments to the Fast Track C400” on
page 14.
Overview of Analog Inputs
Fast Track C400 inputs support microphones,
guitars, keyboards, and other types of instru-
ments. Fast Track C400 has two analog input
channels, labeled “1” and “2”. When recording
stereo sources, use Input 1 for the left input and
Input 2 for the right input.
The two input sections are located so that the
hardware input jacks line up directly behind
their corresponding input controls on the front
panel. This makes it easier to locate channel in-
put connections from the front. Furthermore,
this layout results in the shortest, most direct
signal path to ensure the best possible sound
quality.
Each Input section has three analog input jacks
(the Mic and Line are on a single, combo jack):
Mic For XLR microphone cables.
Line (TRS) For 1/4-inch Tip-Ring-Sleeve cables
from keyboards, mixers, and other line-level
sources.
DI For 1/4-inch Tip-Sleeve cables from guitar,
bass, or similar sources.
Inputs on front panel of Fast Track C400
Inputs on rear panel of Fast Track C400
