Chapter 1: Welcome to Mbox Mini 1
chapter 1
Welcome to Mbox Mini
Welcome to the Mbox
®
Mini USB audio inter-
face from Avid
®
.
Mbox Mini provides your USB-equipped com-
puter with two channels of analog audio input,
two analog monitor outputs, and one head-
phone output. Mbox Mini includes one profes-
sional-quality mic preamp and 24-bit analog-to-
digital and digital-to-analog converters.
Mbox Mini integrates with Pro Tools
®
software,
and is compatible with third-party audio appli-
cations that support the CoreAudio (Mac) or
ASIO (Windows) standard.
Mbox Mini Features
The Mbox Mini provides the following:
• Two channels of analog audio input:
• Combo connector with XLR (microphone)
input and 1/4-inch (line-level) input and
switchable 48V phantom power
• Two 1/4-inch TRS (Tip-Ring-Sleeve) con-
nectors. One input is switchable between
Line and DI level devices. The other is DI
only and switchable with the Combo con-
nector for Input 1
• Gain control with –20 dB pad available sep-
arately on each input channel
• Two 1/4-inch TRS analog monitor outputs
• 1/4-inch (TRS) stereo headphone output with
adjustable level control
• Mon (Monitor) Mute switch for muting mon-
itor outputs, without muting headphone out-
put. This switch does not affect recording
• 24-bit A/D and D/A converters, supporting
sample rates of 44.1 kHz and 48 kHz
• Zero-latency analog record monitoring with
Mix (ratio) knob for adjustable balance be-
tween input and playback
• USB-powered operation
Mbox Mini may not function properly if con-
nected to a USB hub. Connect Mbox Mini to a
separate, dedicated USB port.
